High Mount A/C Bracket for Cummins® 4BT (SKU 3068)

$685.00
(No reviews yet) Write a Review
SKU:
3068

This bracket locates the A/C compressor and alternator high on passenger side to make the Cummins® 4BT conversion friendly into trucks. Works with all Dodge® "Sanden" A/C compressors from 1994-2005.

Includes:

  • Alternator bracket
  • A/C compressor bracket
  • Bolt kit
  • Belt
  • Belt tension bracket
  • O-ring seals
  • Tensioner
  • Installation instructions, including belt routing

Notes:

  • Designed to use a "SBF" Ford gasoline alternator that is original to your F-150 (1992-1996), requires 8 rib pulley: Ford Part #F65Z10344AA
  • No pulley changes for those with a Ford diesel alternator
  • No interference with frame or cross member
  • If you do not have the upper water neck that is pointing straight up (#3285102), you will need to change to Cummins #3285102 DCS SKU 2624
  • If your lower water neck is not pointing down at a 45° angle, you will need to change to Cummins #3934877, DCS SKU 3102 (Note: The included instructions will instruct you on how to make a modification to this lower water neck for A/C compressor clearance.)
  • In order to achieve enough clearance for the A/C compressor, you will need to install a remote oil filter kit. The kit that we have installed, and is currently working with our system, is the PacBrake PB-HP10007. (For use with the filter port size 1”-16UNF. There is also available M27x2.0 oil port option which is part number PB-H10125, you will need to know which port thread you have when ordering.
  • Made of Billet 6061 Aluminum
  • Quick mount A/C solution
Adaptable Engine:
4BT
Ship Separately:
No
Product can be split into multiple boxes:
No
Must Ship Freight:
No
Dimension Height:
4.5000
Dimension Length:
17.0000
Dimension Width:
11.0000
